Machine
LOW CNC MACHINING
Technical specifications
“Are you looking for a CNC solution capable of meeting your most demanding requirements?”
Length: from 1,500 mm to 7,000 mm.
Width: from 800 mm to 2,800 mm.
Height: from 2,200 mm to 3,100 mm.
We offer custom dimensions.
Dimensions & Working strokes
X strokes: from 1,000 mm to 6,500 mm.
Y strokes: from 500 mm to 2,300 mm.
Z strokes: from 0 mm to 600 mm.
.jpg)
Our electro-spindle, available from 1 kW to over 10 kW, offers the power and precision required for custom machining and designs.
Our machines can be adapted to your needs and equipped with various machining tools (spiked milling cutter, diamond milling cutter, wood milling cutter, etc.).
Electro-spindle
& Tools
With 3 to 6 independent suction zones, our vacuum table ensures optimal material retention.
Keep your workspace clean with efficient chip extraction.
(only on our 3-axis machines)
Vacuum table
& Chip extractor
* We offer Low CNC machines (as above) and High CNC machines (Illustration HERE)
BRUSHLESS
MOTOR
Powerful technology delivering a machining speed of 40,000 mm/min with an optical encoder, 1/60° repeatability, and 1/60° resolution.
LATEST GENERATION
CHASSIS
Our KMSYSTEM profiles are ultra-rigid and designed for maximum strength using high-quality materials that guarantee durability and precision during use.
The profiles are developed and designed in France, allowing us to install the machine through standard doors.
PRECISE & EFFICIENT GUIDANCE
Equipped with synchronous steel belts, our machines feature a linear monorail guide with ground ball bearings, protected from dust by a Teflon strip.
The result: increased precision and reduced maintenance costs.
