TRC RANGE
from 32,000€
CNC Machines
This range of digital machines adapts to different industries. From the cutting of foams, cutting textiles but also cutting of leathers and fibers, our cnc also offer the machining of wooden boards, PU foams and the machining of plastic materials.
4-ply dry fiber cutting with triple tool head
Characteristics
A motorization at the forefront
Precise and fast guidance
Rack and ball screw drive
Linear guide monorail, ball bearing
Dustproof protection by teflon tape
Technology Brushless AC Motors
from 100W to 2kW
Optical Encoders
Maximum speed 40 000mm / min
Repeatability <1/60 ° mm
Resolution 1/60 ° mm
A specialized digital control
A KMSYSTEM exclusive that supports 6 simultaneous axes and controls all aspects of the machine. All KMSYSTEM machines benefit from this multidisciplinary core and adapted to each request..
Customized software
The KMSHAPE software is developed within the company. The updates are free and adapted to each one of you. We have the wish to remain at your service because the innovation also comes from you.
Import of all Gcode files.
Compatibility with all CAM software.
Learning mode Joystick control
Latest generation chassis
New ultra-rigid KMSYSTEM profiles.
Anodized Black 130x105 mm
Designed, developed and manufactured in France for maximum reliability.
An optimal suction table
Offering 3 to 6 completely independent suction zones, the company-designed tray adapts to all your productions by reducing your energy consumption.
CRT 2000
TRC 3000
Tools
Rotary Cutter
Variable in diameter, this tool allows you to cut, mark or crush the material of your choice.
Electro-spindle
From 18000 rpm to 36 000 rpm and from 1Kw to 3.3Kw, we adapt the milling machine to your needs. Welcoming all types of tools.
Vibrant knife
With a depth of up to 110 mm, the vibrating knife offers the possibility to cut very precisely all your design even the most complex.
Depression table
Offering 3 to 6 completely independent suction zones.
To satisfy all your needs you also offer an assortment of compatible tools
